Product Details
Product Details
- TIMKEN 69790494879
- Brand:TIMKEN
- Type series:DI-6 Type Hubs - Rough Stock Bore
- Model:69790494879
Product parameters
| Specifications | |||
| Description | DI90-6 HUB RSB | ||
|---|---|---|---|
| Hub Style | Standard | ||
| Type | Disc Coupling Hubs | ||
| Hub Material | AISI 1045 | ||
| Style | Unbored | ||
| Color | Metallic | ||
| Bore Type | Rough Stock Bore | ||
| Coupling Series | DI-6 | ||
| Coupling Type | Disc | ||
| Weight | 2.10 lb | ||
| Weight (Complete Coupling w/ Max. Bores) | 8.00 lb | ||
| Dimensional Data | |||
| Size | 90-6 | ||
|---|---|---|---|
| Set Screw Style Coupling Size (Dimension T) | No Setscrew | ||
| Length thru Bore | 39.88 mm 1.570 in | ||
| Overall Length | 159.00 mm 6.25 in | ||
| Max. Bore (Dimensions ID1/ID2) | 43 mm 1.68 in | ||
| Dimension FD | 94.00 mm 3.700 in | ||
| Dimension HD | 60.00 mm 2.360 in | ||
| Dimension S | 32.00 mm 1.270 in | ||
| Distance between Shaft Ends (Dimension BSE) | 79.00 mm 3.110 in | ||
| Cubic inches | 21.49330 in3 | ||
| Performance Data | |||
| Nominal Torque | 2100 in·lb | ||
|---|---|---|---|
| Max. Torque | 4200 in·lb | ||
| Max. Speed (Unbalanced) | 9100 rpm | ||
| Max. Speed (Balanced) | 22700 rpm | ||
| Axial Misalignment (∆ Ka) | 0.059 in | ||
| Max. Angular Misalignment | 1.50 o | ||
| Torsional Stiffness x 106 | 2.40 in·lb/rad | ||
| Rated Power at 100 rpm | 2.60 kW | ||
| Features | |||
| Features |
| ||
|---|---|---|---|
