Product Details
Product Details
- TIMKEN 69790491583
- Brand: TIMKEN
- Type series: FLAMM Type Hubs - Rough Stock Bore
- Model: 69790491583
Product parameters
| Specifications | |||
| Description | FLAMM 1.5 HUB RSB | ||
|---|---|---|---|
| Hub Style | Exposed Bolt | ||
| Type | Gear Coupling Hubs | ||
| Hub Material | All Metal | ||
| Style | Unbored | ||
| Color | Metallic | ||
| Bore Type | Rough Stock Bore | ||
| Coupling Type | Gear | ||
| Weight | 4.69 lb | ||
| Complete Coupling Weight | 24.00 lb | ||
| Dimensional Data | |||
| Size | 1 1/2 | ||
|---|---|---|---|
| Max. Bore (Dimensions ID1/ID2) | Series 41 mm 1.625 in | ||
| Dimension BSE1 | 4.06 mm 0.160 in | ||
| Dimension D (type) | 100.84 mm 3.970 in | ||
| Dimension FD | 152.40 mm 6.00 in | ||
| Dimension HD | 55.63 mm 2.190 in | ||
| Dimension HD1 | 100.84 mm 3.970 in | ||
| Dimension LTB1 | 46.74 mm 1.840 in | ||
| Distance between Shaft Ends (Dimension BSE) | 3.30 mm 0.13 in | ||
| Cubic inches | 17.07412 in3 | ||
| Performance Data | |||
| Nominal Torque | 2140 N (type)·m 18900 in·lb | ||
|---|---|---|---|
| Max. Speed (Unbalanced) | 5500 rpm | ||
| Max. Speed (Balanced) | 8250.00 rpm | ||
| Parallel Misalignment | 0.280 in | ||
| Max. Angular Misalignment | 1.50o per Gear Mesh | ||
| Features | |||
| Features |
| ||
|---|---|---|---|
| Notes | |||
| Notes |
| ||
|---|---|---|---|
